ePHASORSIM
OP204
Electro-mechanical real-time simulation
This course is intended for new ePHASORSIM users who want to learn Phasor Domain real-time simulation. ePHASORSIM simulates electro-mechanical transient stability phenomena of very large power grids with thousands of buses, generators, transformers, transmission lines, loads and controllers.
Duration
e-Learning: at your own pace, In-person: 1 day, Online: 4 hours
Type
Product training
Prerequisites
OP101: RT-LAB - Real-Time Simulation Systems Fundamentals
Grasp core concepts
Understand the concept of Phasor Domain simulation features, benefits and limitations
Integrate with design tools
Import PSS/E, DIgSILENT or other model-based design tools into ePHASORSIM
Bridge connections
Connect I/Os and communication buses with ePHASORSIM
Explore system interactions
Learn about the interaction of ePHASORSIM and RT-LAB
e-learning Course content
What you will learn through e-Learning
Section 1 – Getting Started
Video 1 – Introduction
Video 2 – Solver Block
Section 2 – ePHASORSIM Native Library
Video 3 – IO pins file
Video 4 – Native Library – Network Example
Section 3 – Third Party Format Import
Video 5 – PSS®E Network Import
Video 6 – CYME Network Import
Video 7 – PowerFactory Network Import
Section 4 – Simulation: Settings, Power Flow, Dynamic Simulation
Video 8 – Simulation Settings and Power Flow
Section 5 – Advanced Features
Video 9 – ePHASORSIM Python API
Formats
Choose between our available formats
On-Site training
Our engineers travel the world to deliver personalized training sessions at your office or university.
Head-office training
Hosted at our head office or one of our subsidiaries, offering an in-person training with our specialists.
e-Learning (free for customers)
A training course taken online at your own pace. e-Learning courses are free for our customers.
Online remote training
Online remote training sessions are conducted via videoconference, allowing great flexibility for attendees.
Start your training right now
Gain the knowledge you need to make the most of your OPAL-RT products and achieve optimal results.
FAQ
We’re here to make sure that you get the most out of your real-time system.
How do I request this training?
To register for a training course, fill out the training request form to get started. Be sure to specify the course you would like to take and the preferred format.
Will I receive a certification upon completion?
Yes, participants who complete the training successfully will receive a certificate of completion.
How do I get access to OPAL-RT’s e-learning platform?
To get access to our e-Learning platform, simply select ‘e-Learning’ on the training request form. Our customers are eligible for free access to the e-Learning platform.
How much does this training cost?
Course pricing depends on the selected format. Our customers get access to e-learning at no additional cost.
