PHIL Prime Test Bench OP1430PR
Product Brochure, Hardware-In-the-Loop (HIL), Power Hardware-In-the-Loop (PHIL), Power Systems
2026-09-30
The PHIL Prime Test Bench OP1430PR brochure introduces OPAL-RT TECHNOLOGIES' scalable and reconfigurable solution for Power Hardware-In-the-Loop (PHIL) and Hardware-In-the-Loop (HIL) testing across Power System and Microgrid applications. Designed to bridge real-time simulation and physical equipment, the OP1430PR supports smart inverter testing, distributed energy resource (DER) emulation, renewable energy integration, motor drives, and Microgrid Cybersecurity research. Featuring high-fidelity OP8111 4Q Power Amplifier technology, parallel power boosting from 5 kW to 30 kW, configurable AC and DC outputs, and Smart Bus Bars for connecting multiple devices under test, this versatile platform delivers precise and reliable performance. Fully compatible with RT-LAB and HYPERSIM simulation software, the PHIL Prime Test Bench OP1430PR includes validated microgrid models, preconfigured PHIL interfaces, and intuitive monitoring dashboards to simplify laboratory integration, automate testing, and adjust parameters in real time. Ideal for academic research, industrial development, and end-of-line testing, this integrated solution enables engineers to efficiently develop, test, and validate complex power electronics and next-generation energy systems.
