OPAL-RT's time synchronization interface, which includes a kit and software driver, allows users to timestamp their models running on a Real-Time Simulator and to perform different synchronization configurations. There are three connectors available:
About IRIG-B, 1PPS and IEEE-1588
IRIG time code B (IRIG-B) is widely used in the electrical power industry. IRIG-B has a pulse rate of 100 pulses-per-second with an index count of 10 milliseconds over its one-second time frame. It contains time-of-year and year information in a BCD format, and (optionally) seconds-of-day in SBS.
A pulse per second (PPS or 1PPS) is an electrical signal that has a width of less than one second and a sharply rising or abruptly falling edge that accurately repeats once per second.
IEEE-1588 is the standard that defines a protocol enabling precise synchronization of clocks in measurement and control systems implemented with technologies such as network communication, local computing and distributed objects.
