Hybrid and Electrical Transportation
For hardware-in-the-loop (HIL) and power hardware-in-the-loop (PHIL) testing of electronic control units, real-time simulations must be as accurate as possible. A reliable test environment for electric and hybrid vehicle applications requires high-fidelity models, ultra-fast control loops, and the fastest possible input-output communication. Our FPGA-based simulation software operates with nanosecond-level time steps, ensuring unmatched precision and performance in real-time testing. Combined with powerful solvers and CPU capabilities, we provide the technology needed to push the boundaries of electric vehicle innovation.
They trust us
Advantages
Why choose OPAL-RT?
Working extensively with the industry and top research laboratories in the world, our expertise in HIL systems offers many benefits in energy conversion control applications.
01
High-fidelity FPGA real-time motor simulation
We provide FPGA and Simulink-based electrical motor models, such as: PMSM, IM, SRM, BLDC, DC and AC. See more FPGA Electric Machine Library
02
Virtual fault injection
Our solution enables the simulation of faults, such as open, short-circuit, or gate fault on any IGBT, possible motor open-line and line-line faults, DC-link faults, resolver sensor non-idealistic behavior.
03
End-to-end power electronics and HIL simulation capabilities
Our FPGA-based solvers allow ultra-fast switching simulations (nanosecond time steps) for EV/HEV inverters, DC-DC converters, and onboard chargers.
04
Trusted by industry leaders, driven by innovation
With over 25 years of experience, we deliver real-time simulation solutions that push the boundaries of technology and help you build the future with confidence.
Products
Essentials for testing power electronics applications
Discover the tools that professionals depend on for accurate and precise testing. Ensure optimal performance with our products.
Ultra-Fast EMT Simulation and HIL Testing
eHS
Advanced FPGA technology for high-fidelity, low-latency, power systems and power electronics simulation, enabling HIL testing across energy, automotive, aerospace, and industrial applications.
Multi-Domain, Simulink®-based HIL
RT-LAB
Fully integrated with MATLAB/Simulink® and best combined with our various toolboxes to bring multi-domain Simscape™ Electrical™ and SimPowerSystems models to real time for fast control development.
High-end Simulator
OP5707XG
Unequalled level of performance in a co-simulation platform, featuring an AMD Virtex™-7 FPGA and up to 44 cores of the latest Intel® Xeon® CPUs, both required for power systems and power electronics applications.
FAQ
Find the answers to your questions
What communication protocols do you support?
Consult our comprehensive list of supported protocols here: Communication Protocols.
What makes OPAL-RT’s electric vehicle simulation solutions unique?
Our electric vehicle simulation solutions offer ultra-fast, high-fidelity real-time performance using FPGA- and CPU-based systems. Our EV simulation software enables nanosecond-level time steps, making it ideal for HIL and PHIL testing of complex electric and hybrid vehicle control units.
How does OPAL-RT support hybrid vehicle simulation and testing?
Our platform provides real-time hybrid vehicle simulation using advanced electrical and motor models, enabling the accurate testing of ECUs and power converters. Engineers can validate hybrid drivetrains and power electronics with scalable EV testing equipment and powerful simulation tools.
What capabilities does your electric vehicle simulation software offer?
Our electric vehicle simulation software supports full electric vehicle modelling and simulations, from virtual fault injection to high-speed inverter and charger validation. It integrates with tools like MATLAB/Simulink and supports custom models for advanced EV simulation tasks.
Can I use OPAL-RT’s solutions for EV charging simulation?
Yes, we offer a specialized simulation tool for EV charging that allows real-time testing of onboard chargers, DC-DC converters, and grid interaction. Our EV simulation platform ensures safe and efficient validation of EV charging systems before deployment.
What kind of EV testing equipment does OPAL-RT provide?
We offer a full range of EV testing equipment, including FPGA-based simulators, HIL systems, and electric vehicle simulation software. These tools are designed to deliver precise control and measurement capabilities for EV and hybrid systems development.
